Poly Transporter 2M3

Capacity and dimensions

• Usable volume: 2 m³ (2000 L).
• Payload: 150 kg.
• Gross vehicle weight rating (GVWR): 435 kg.
• Overall vehicle dimensions: 2.7 m (length) x 1.1 m (width) x 0.98 m (height of bare chassis).
• Vehicle weight: 73 kg.
• Maximum gradient: Valeo: 0 to 18% / Bafang: 0 to 15%.
• Turning radius: 180 cm.
• Ground clearance: 150 mm.

Motor and power

• Available motors: Valeo Cyclee system (with integrated 7-speed automatic gearbox) or Bafang M500-510 (5-speed manual gearbox).
• Power and speed: 250 W motor delivering powerful torque of 130 Nm (Valeo) or 95 Nm (Bafang). Maximum assisted speed is 25 km/h.
• Battery (Valeo): Ultra r1240 lithium-ion technology providing 1254 Wh. 40 km range. Full recharge time is 8 to 9 hours (designed for 600 cycles).
• Battery (VUF): 1440 Wh lithium-ion, offering a range of approximately 50 km. Designed for a lifespan of up to 2500 charge cycles (compatible with Bafang and Valeo).
• Battery (Bafang): 450 or 600 Wh lithium-ion. 20 to 30 km range. Full recharge time is 4 to 5 hours (designed for 1000 cycles).

Transport box design (Poly)

• Materials: aluminum corners and honeycomb polypropylene panels.
• External box dimensions: 1.517 m (length) x 0.977 m (width) x 1.467 m (height).
• Internal box dimensions: 1.475 m (length) x 0.935 m (width) x 1.421 m (height).
• Access and openings: loading and unloading are made easy by a dual opening (side and rear). The rear door offers a clear opening of 1379 mm high by 927 mm wide. The side door offers 1183 mm high by 650 mm wide.
• Cargo security: locking by mechanical key lock or RFID badge-and-button lock.
• Customization: the exterior surface of the box can be fully wrapped with your brand image.

Cycle parts and chassis

• Frame and fork: made of 4130 chromoly steel with a 15 mm axle. The fork is rigid.
• Drivetrain: reinforced chains designed for cargo bikes and a heavy-duty differential for maximum durability.
• Wheels: 24-inch spoked front rims. 20-inch aluminum mag rear wheels. The front hub is a dedicated cargo hub.
• Tires: 24x2.5 front tire. 20x3.0 rear tires.
• Braking: high-performance hydraulic system. 2-piston front brake with 203 mm disc. Dual hydraulic calipers at the rear (2 pistons, 203 mm disc).

Ergonomics, equipment and accessories

• Cockpit: 6061 aluminum handlebar (31.8 mm diameter, 760 mm width) with adjustable stem. Equipped with ergonomic grips.
• Comfort: "Confort +" saddle and a very low 450 mm step-through for effortless dismounting.
• Safety and visibility: adjustable wide-angle mirrors included. The lighting system includes a 12 V dynamo front light, a brake light and turn signals at the front (on the handlebar) and rear (on the box or frame).
• Practicality: black steel mudguards.
