Active Cold

Capacity and Dimensions

• Cargo volume: 1.5 m³ (1,500 liters).
• Payload: 150 kg.
• Gross Vehicle Weight Rating (GVWR): 435 kg.
• Overall vehicle dimensions: 2.7 m (length) x 1.1 m (width) x 1.73 m (height).

Motorization and Power (Valeo Exclusive)

To ensure optimal performance, especially when transporting heavy loads with the cooling unit in operation, the Active Cold model is offered exclusively with the high-end Valeo motor system.

• Motor: Valeo Cyclee system with integrated automatic transmission.
• Power and Torque: 250 W motor delivering an exceptional 130 Nm of torque.
• Maximum speed: 25 km/h.
• Main battery: Ultra r1240 lithium-ion technology with a 1254 Wh capacity.
• Range & Charging: Up to 50 km of range. Full recharge time is 8 to 9 hours. The battery is designed to withstand approximately 600 charge cycles.

Active Cold Refrigerated Box Design

• Thermal Performance: Box specially designed to maintain the cold chain. Ideal for food delivery, pharmaceuticals, or any other products requiring temperature-controlled transport.
• Materials: Robust, waterproof, and 100% recyclable design, featuring UV protection.
• External box dimensions: 1.26 m (Length) x 0.83 m (Width) x 1.32 m (Height).
• Openings (Dual access): Loading and unloading are optimized thanks to two access points.
  • Rear door: Clear opening of 1263 mm (Height) x 823 mm (Width).
  • Side door: Clear opening of 1053 mm (Height) x 600 mm (Width).
• Security: Mechanical lock or RFID electronic lock (badge and button).
• Customization: The exterior surfaces of the box can be fully customized with a wrap featuring your brand identity.

Cycle Part and Chassis

• Frame and Fork: 4130 chromoly steel frame with a matte black finish. Rigid fork with a 9 mm axle.
• Drivetrain: Reinforced chains designed for cargo bikes, paired with a heavy-duty differential.
• Wheels: * Front: 24-inch triple-wall aluminum rim with a specialized cargo hub.
  • Rear: 20-inch aluminum mag wheels.
• Tires: 24x2.5 front tire and 20x3.0 rear tires.
• Braking (High Performance): Fully hydraulic system. Front: 2-piston caliper with a 203 mm disc. Rear: dual 2-piston calipers with 160 mm discs for powerful, reliable stopping power, even when fully loaded.

Ergonomics, Equipment, and Accessories

• Cockpit: 6061 aluminum handlebar (760 mm wide, 31.8 mm diameter) featuring ergonomic grips and an adjustable stem.
• Rider Comfort: "Comfort +" saddle mounted on a suspension seat post (27.2 mm diameter) with a quick-release clamp.
• Safety and Visibility: Adjustable wide-angle mirrors. Complete lighting system including a headlight, taillights, brake lights, and turn signals.
• Standard Accessories: Steel platform rack, steel pedals with non-slip surfaces and reflectors, black steel fenders, frame lock (horseshoe style), and a waterproof magnetic smartphone mount.

‍
